TDA22590XUMA1

TDA22590XUMA1

Product ModelTDA22590XUMA1
ManufactureInfineon
DescriptionPOWERSTAGE CE
StockAvailable

Product Details

POWERSTAGE CE

Description

Infineon TDA22590XUMA1 is an integrated smart power stage (SPS) optimized for high-frequency, multiphase DC-DC converters powering CPUs, GPUs, FPGAs, and DDR memory arrays.



Performance:The TDA22590XUMA1 operates with an input voltage range of 4.25 V to 16 V and delivers output voltages from 0.225 V up to 5.5 V with a continuous output current capability of 90 A. It supports switching frequencies up to 2 MHz, enabling high-performance transient response and miniaturization of passive components.



Features: The TDA22590XUMA1 integrates a low quiescent current synchronous buck gate-driver IC, control MOSFET, synchronous MOSFET, and Schottky diode in a single package. It features on-chip MOSFET current sensing and reporting at 5 µA/A, cycle-by-cycle overcurrent protection (OCP), control MOSFET short detection (HSS), over-temperature protection with thermal shutdown, VDRV and bootstrap undervoltage protection, and advanced fault reporting for phase fault identification in multiphase configurations.



Package:The TDA22590XUMA1 is housed in a PG-UFLGA-34 (34-PowerUFLGA) package with a compact 4 mm × 6 mm × 0.465 mm chip-embedded (CE) form factor, optimized for PCB layout, thermal transfer, and minimal switch node ringing. It operates over a junction temperature range of -40°C to 125°C and is RoHS compliant.



Product Specifications

ParameterTDA22590XUMA1
Package / Case34-Power UFLGA
Pin Count34
Mounting TypeSurface Mount
PackagingTape & Reel (TR)
Operating Temperature-40°C to +125°C
Moisture Sensitivity Level (MSL)MSL 3
RoHS StatusRoHS Compliant

Description

Infineon TDA22590XUMA1 is an integrated smart power stage (SPS) optimized for high-frequency, multiphase DC-DC converters powering CPUs, GPUs, FPGAs, and DDR memory arrays.



Performance:The TDA22590XUMA1 operates with an input voltage range of 4.25 V to 16 V and delivers output voltages from 0.225 V up to 5.5 V with a continuous output current capability of 90 A. It supports switching frequencies up to 2 MHz, enabling high-performance transient response and miniaturization of passive components.



Features: The TDA22590XUMA1 integrates a low quiescent current synchronous buck gate-driver IC, control MOSFET, synchronous MOSFET, and Schottky diode in a single package. It features on-chip MOSFET current sensing and reporting at 5 µA/A, cycle-by-cycle overcurrent protection (OCP), control MOSFET short detection (HSS), over-temperature protection with thermal shutdown, VDRV and bootstrap undervoltage protection, and advanced fault reporting for phase fault identification in multiphase configurations.



Package:The TDA22590XUMA1 is housed in a PG-UFLGA-34 (34-PowerUFLGA) package with a compact 4 mm × 6 mm × 0.465 mm chip-embedded (CE) form factor, optimized for PCB layout, thermal transfer, and minimal switch node ringing. It operates over a junction temperature range of -40°C to 125°C and is RoHS compliant.



Product Specifications

ParameterTDA22590XUMA1
Package / Case34-Power UFLGA
Pin Count34
Mounting TypeSurface Mount
PackagingTape & Reel (TR)
Operating Temperature-40°C to +125°C
Moisture Sensitivity Level (MSL)MSL 3
RoHS StatusRoHS Compliant
