| Product Model | MPU-9250 |
|---|---|
| Manufacture | TDK |
| Description | IMU ACCEL/GYRO/MAG I2C/SPI 24QFN |
| Stock | Available |
IMU ACCEL/GYRO/MAG I2C/SPI 24QFN
Overview：TDK InvenSense MPU-9250 is a 9-axis Motion Tracking IMU that integrates a 3-axis gyroscope, 3-axis accelerometer, and 3-axis magnetometer in a compact QFN-24 package. It is designed for motion sensing, orientation tracking, and 9-axis motion-processing applications in compact electronic systems. The MPU-9250 has been discontinued.
Performance：MPU-9250 supports programmable gyroscope full-scale ranges of ±250, ±500, ±1000, and ±2000°/s, and accelerometer ranges of ±2, ±4, ±8, and ±16g. Its integrated 9-axis sensing architecture enables simultaneous measurement of angular velocity, linear acceleration, and magnetic field for motion-tracking applications.
Features：MPU-9250 combines a 3-axis gyroscope, 3-axis accelerometer, and 3-axis magnetometer into a single motion-sensing device, reducing component count and simplifying system design. It is suitable for applications such as wearable devices, portable electronics, gaming equipment, remote controls, and other motion-tracking systems.
Package & Status：MPU-9250 is housed in a compact 24-pin QFN package, making it suitable for space-constrained designs and surface-mount assembly. The device is branded by TDK InvenSense and is a 9-Axis Motion Sensor / 9-Axis Motion Tracking IMU that has been discontinued.
| Parameter | MPU-9250 |
| Package / Case | 24-TFQFN, Exposed Pad, 3 × 3 mm |
| Pin Count | 24 |
| Mounting Type | Surface Mount |
| Packaging | Tape & Reel (TR) |
| Operating Temperature | -40°C to +85°C |
| Moisture Sensitivity Level (MSL) | MSL 3 (168 Hours) |
| RoHS Status | RoHS Compliant |
Overview：TDK InvenSense MPU-9250 is a 9-axis Motion Tracking IMU that integrates a 3-axis gyroscope, 3-axis accelerometer, and 3-axis magnetometer in a compact QFN-24 package. It is designed for motion sensing, orientation tracking, and 9-axis motion-processing applications in compact electronic systems. The MPU-9250 has been discontinued.
Performance：MPU-9250 supports programmable gyroscope full-scale ranges of ±250, ±500, ±1000, and ±2000°/s, and accelerometer ranges of ±2, ±4, ±8, and ±16g. Its integrated 9-axis sensing architecture enables simultaneous measurement of angular velocity, linear acceleration, and magnetic field for motion-tracking applications.
Features：MPU-9250 combines a 3-axis gyroscope, 3-axis accelerometer, and 3-axis magnetometer into a single motion-sensing device, reducing component count and simplifying system design. It is suitable for applications such as wearable devices, portable electronics, gaming equipment, remote controls, and other motion-tracking systems.
Package & Status：MPU-9250 is housed in a compact 24-pin QFN package, making it suitable for space-constrained designs and surface-mount assembly. The device is branded by TDK InvenSense and is a 9-Axis Motion Sensor / 9-Axis Motion Tracking IMU that has been discontinued.
| Parameter | MPU-9250 |
| Package / Case | 24-TFQFN, Exposed Pad, 3 × 3 mm |
| Pin Count | 24 |
| Mounting Type | Surface Mount |
| Packaging | Tape & Reel (TR) |
| Operating Temperature | -40°C to +85°C |
| Moisture Sensitivity Level (MSL) | MSL 3 (168 Hours) |
| RoHS Status | RoHS Compliant |
