| Product Model | ISL99360FRZ-T |
|---|---|
| Manufacture | Renesas |
| Description | SMART POWER STAGE GEN2 (SPS) MOD |
| Stock | Available |
SMART POWER STAGE GEN2 (SPS) MOD
Overview：Renesas ISL99360FRZ-T is a 60A Smart Power Stage (SPS) designed for high-frequency, high-efficiency multiphase DC/DC power conversion, integrating power MOSFETs, gate drivers, and high-accuracy current and temperature monitoring in a compact 32-pin 5x5mm PQFN package.
Performance：ISL99360FRZ-T supports 3.0V to 16V input operation and up to 60A DC current, with switching frequencies up to 1.25MHz. Its integrated current monitor provides ±3% accuracy, supporting precise current monitoring in multiphase power architectures.
Protection & Monitoring： ISL99360FRZ-T integrates current and temperature monitoring along with overcurrent, over-temperature, high-side FET short-circuit, and VIN/VCC undervoltage-lockout protection. A tri-state PWM interface and open-drain fault reporting further support robust system control.
Package & Applications：ISL99360FRZ-T is housed in a thermally enhanced 32-pin PQFN 5x5mm package, providing a compact footprint for high power density designs. It is suitable for multiphase VRM/VRD, processor core/graphics/memory regulators, server and networking power, cloud computing, and high-current point-of-load DC/DC applications.
| Parameter | ISL99360FRZ-T |
| Package / Case | 32-PowerWFQFN |
| Pin Count | 32 |
| Mounting Type | Surface Mount |
| Packaging | Tape & Reel (TR) |
| Operating Temperature | -40°C to +85°C |
| Moisture Sensitivity Level (MSL) | MSL 3 (168 Hours) |
| RoHS Status | RoHS3 Compliant |
Overview：Renesas ISL99360FRZ-T is a 60A Smart Power Stage (SPS) designed for high-frequency, high-efficiency multiphase DC/DC power conversion, integrating power MOSFETs, gate drivers, and high-accuracy current and temperature monitoring in a compact 32-pin 5x5mm PQFN package.
Performance：ISL99360FRZ-T supports 3.0V to 16V input operation and up to 60A DC current, with switching frequencies up to 1.25MHz. Its integrated current monitor provides ±3% accuracy, supporting precise current monitoring in multiphase power architectures.
Protection & Monitoring： ISL99360FRZ-T integrates current and temperature monitoring along with overcurrent, over-temperature, high-side FET short-circuit, and VIN/VCC undervoltage-lockout protection. A tri-state PWM interface and open-drain fault reporting further support robust system control.
Package & Applications：ISL99360FRZ-T is housed in a thermally enhanced 32-pin PQFN 5x5mm package, providing a compact footprint for high power density designs. It is suitable for multiphase VRM/VRD, processor core/graphics/memory regulators, server and networking power, cloud computing, and high-current point-of-load DC/DC applications.
| Parameter | ISL99360FRZ-T |
| Package / Case | 32-PowerWFQFN |
| Pin Count | 32 |
| Mounting Type | Surface Mount |
| Packaging | Tape & Reel (TR) |
| Operating Temperature | -40°C to +85°C |
| Moisture Sensitivity Level (MSL) | MSL 3 (168 Hours) |
| RoHS Status | RoHS3 Compliant |
