| Product Model | ICM-42688-P |
|---|---|
| Manufacture | TDK |
| Description | Accelerometer, gyroscope, 6-axis sensor output |
| Stock | Available |
Accelerometer, gyroscope, 6-axis sensor output
Overview：TDK InvenSense ICM-42688-P is a high-performance 6-axis MEMS motion tracking IMU integrating a 3-axis gyroscope and 3-axis accelerometer in a compact LGA-14 package measuring 2.5 × 3 × 0.91 mm. Designed for low-noise, low-power motion sensing, it is suitable for wearable devices, IoT equipment, robotics, and other space-constrained applications.
Performance：ICM-42688-P combines a 3-axis gyroscope with selectable full-scale ranges from ±15.625 to ±2000 dps and a 3-axis accelerometer with selectable ranges from ±2 g to ±16 g. Its low-noise sensing performance supports accurate motion and orientation tracking in demanding applications.
Features：ICM-42688-P integrates a 2 KB FIFO, programmable digital filters, programmable interrupts, and embedded motion functions such as pedometer, tilt detection, tap detection, and wake-on-motion. It supports I3C, I²C, and SPI interfaces for flexible system integration.
Package & Applications：ICM-42688-P is housed in a compact LGA-14 package with dimensions of 2.5 × 3 × 0.91 mm, making it well suited for space-constrained designs. As a 6-Axis Motion Tracking IMU and TDK InvenSense 6-Axis IMU Sensor, it is designed for wearable electronics, IoT devices, robotics, AR/VR equipment, and other motion-tracking applications.
| Parameter | ICM-42688-P |
| Package / Case | LGA-14 |
| Pin Count | 14 |
| Mounting Type | Surface Mount (SMD/SMT) |
| Packaging | Tape & Reel (TR) |
| Operating Temperature | -40°C to +85°C |
| Moisture Sensitivity Level (MSL) | MSL 1 (Unlimited) |
| RoHS Status | RoHS3 Compliant |
Overview：TDK InvenSense ICM-42688-P is a high-performance 6-axis MEMS motion tracking IMU integrating a 3-axis gyroscope and 3-axis accelerometer in a compact LGA-14 package measuring 2.5 × 3 × 0.91 mm. Designed for low-noise, low-power motion sensing, it is suitable for wearable devices, IoT equipment, robotics, and other space-constrained applications.
Performance：ICM-42688-P combines a 3-axis gyroscope with selectable full-scale ranges from ±15.625 to ±2000 dps and a 3-axis accelerometer with selectable ranges from ±2 g to ±16 g. Its low-noise sensing performance supports accurate motion and orientation tracking in demanding applications.
Features：ICM-42688-P integrates a 2 KB FIFO, programmable digital filters, programmable interrupts, and embedded motion functions such as pedometer, tilt detection, tap detection, and wake-on-motion. It supports I3C, I²C, and SPI interfaces for flexible system integration.
Package & Applications：ICM-42688-P is housed in a compact LGA-14 package with dimensions of 2.5 × 3 × 0.91 mm, making it well suited for space-constrained designs. As a 6-Axis Motion Tracking IMU and TDK InvenSense 6-Axis IMU Sensor, it is designed for wearable electronics, IoT devices, robotics, AR/VR equipment, and other motion-tracking applications.
| Parameter | ICM-42688-P |
| Package / Case | LGA-14 |
| Pin Count | 14 |
| Mounting Type | Surface Mount (SMD/SMT) |
| Packaging | Tape & Reel (TR) |
| Operating Temperature | -40°C to +85°C |
| Moisture Sensitivity Level (MSL) | MSL 1 (Unlimited) |
| RoHS Status | RoHS3 Compliant |
