| Product Model | AD9361BBCZ-REEL |
|---|---|
| Manufacture | ADI |
| Description | IC RF TXRX CELLULAR 144CSPBGA |
| Stock | Available |
IC RF TXRX CELLULAR 144CSPBGA
Overview: Analog Devices AD9361BBCZ-REEL is a high-performance Wideband RF Transceiver designed for software-defined radio (SDR), base stations and general-purpose wireless communication systems. It integrates a 2×2 RF transceiver, 12-bit ADCs/DACs and frequency synthesizers, supporting TX frequencies from 47 MHz to 6.0 GHz, RX frequencies from 70 MHz to 6.0 GHz, and tunable channel bandwidths below 200 kHz to 56 MHz.
Performance: AD9361BBCZ-REEL supports both TDD and FDD operation, with integrated automatic gain control, digital filtering and fractional-N synthesizers. Its flexible RF architecture is suitable for wideband signal processing and wireless communication designs, including 3G/4G base stations and SDR platforms.
Features: AD9361BBCZ-REEL integrates dual receivers and dual transmitters with a CMOS/LVDS digital interface, providing programmable RF operation and multichip synchronization. The device combines the RF front end, mixed-signal baseband and frequency synthesis functions to simplify system integration.
Package: AD9361BBCZ-REEL uses a 144-Ball CSPBGA (10 mm × 10 mm × 1.7 mm) surface-mount package, with a −40°C to +85°C operating temperature range. The -REEL ordering version is supplied on reel in quantities of 1,500 units, making it suitable for automated assembly.
| Parameter | AD9361BBCZ-REEL |
| Package / Case | 144-LFBGA, CSPBGA |
| Pin Count | 144 |
| Mounting Type | Surface Mount |
| Packaging | Tape & Reel (TR), 1,500 pcs/reel |
| Operating Temperature | -40°C to +85°C |
| Moisture Sensitivity Level (MSL) | MSL 3 (168 Hours) |
| RoHS Status | RoHS Compliant |
Overview: Analog Devices AD9361BBCZ-REEL is a high-performance Wideband RF Transceiver designed for software-defined radio (SDR), base stations and general-purpose wireless communication systems. It integrates a 2×2 RF transceiver, 12-bit ADCs/DACs and frequency synthesizers, supporting TX frequencies from 47 MHz to 6.0 GHz, RX frequencies from 70 MHz to 6.0 GHz, and tunable channel bandwidths below 200 kHz to 56 MHz.
Performance: AD9361BBCZ-REEL supports both TDD and FDD operation, with integrated automatic gain control, digital filtering and fractional-N synthesizers. Its flexible RF architecture is suitable for wideband signal processing and wireless communication designs, including 3G/4G base stations and SDR platforms.
Features: AD9361BBCZ-REEL integrates dual receivers and dual transmitters with a CMOS/LVDS digital interface, providing programmable RF operation and multichip synchronization. The device combines the RF front end, mixed-signal baseband and frequency synthesis functions to simplify system integration.
Package: AD9361BBCZ-REEL uses a 144-Ball CSPBGA (10 mm × 10 mm × 1.7 mm) surface-mount package, with a −40°C to +85°C operating temperature range. The -REEL ordering version is supplied on reel in quantities of 1,500 units, making it suitable for automated assembly.
| Parameter | AD9361BBCZ-REEL |
| Package / Case | 144-LFBGA, CSPBGA |
| Pin Count | 144 |
| Mounting Type | Surface Mount |
| Packaging | Tape & Reel (TR), 1,500 pcs/reel |
| Operating Temperature | -40°C to +85°C |
| Moisture Sensitivity Level (MSL) | MSL 3 (168 Hours) |
| RoHS Status | RoHS Compliant |
